Profile bending machine RB3

powerful and extremely diverse

The profile bending machine type RB3 offers high bending capacity in combination with unparalleled flexibility. The high-torque, hydraulic direct drives of the profile bending machine are maintenance-free and overload-proof. Every roller is individually and directly driven. No chain drives or sliding clutches are used.

The high roller bending capacity of the profile bending machine – of 7.5 kW – in combination with the high-torque direct drives also offers sufficient reserves for bending heavy-duty profiles.

It is therefore possible to bend numerous bending parts to the target radius with just a single pass through the rollers.

Damage to the profile is avoided, optimum bending quality is guaranteed and the maximum in productivity is attained.

The application area of the profile bending machine RB3 can be expanded with a wide range of options. The machine can be equipped with a fourth roller, CNC-controlled side rollers, double rollers or a mandrel bending device. The profile bending machine RB3 offers a suitable solution for almost every bending task. The high flexibility and numerous options make the RB3 one of the most flexible and powerful profile bending machines in the world.

APPLICATION: Metal construction, stairway construction, metalwork, machine construction, conveyance engineering, plant construction, pipework construction, façade construction, swimming pool halls, contract bending companies, utility vehicle construction



TECHNICAL DATA / CHRACTERISTICS

 Bending capacity 7,5 KW
 Driven rollers 3
 Adjustable speed 0-16 stepless
 Shaft diameter 65mm
 Shaft length 200mm (300mm optional)
 Side roller spacing 380-1100mm adjustable
(min. 200mm optional)
 X-asis stroke 250mm
 Pressing force 25 tonnes
 Weight 1300-1500 kg
 Connection 400 V, 32A
 Bending direction away from the machine
 Mobile machine Optional
 Rotation mashine Optional
 Automatic radius control / R-Control Optional
 Hydraulic support rollers Optional
 CNC-Controlled support rollers Optional

CHARACTERISTICS

  • Impressively diverse and powerful
  • The ideal machine for almost every bending task
  • Bends aluminium and steel profiles with top quality and precision
  • Optimum alignment of the machine to the profile to be bent
  • Minimal deformation of the bent profiles
